LW 160 E

The user-friendly LW 160 E with electric drive is ideal for mobile applications or occasional filling operations. It comes wired with power cable, plug and phase selector.
The model differs in E and E 1 (E- three pase / E1-single phase version).


Specifications

  • Electro Motor (Standard: 400V, 3 phase, 50Hz)
  • Power cable with plug and phase selector
  • Start/Stop Switch
  • Stainless steel frame
  • Manual condensate drain
  • Pressure maintaining and non return valve
  • 1x Filling hose c/w filling valve and pressure gauge
  • Intermediate coolers
  • Oil- / Water separators after 2nd and 3rd stage
  • Safety valves after each stage
  • Filling pressure to your choice (200 or 300 bar)
  • Connections to your choice
    (DIN 200 bar or 300 bar, CGA 200 bar or 300 bar and INT)
  • Breathing air purification an accordance to EN 12021


Options

  • Additional filling hose c/w filling valve
  • Automatic condensate drain
  • Automatic stop at final pressure c/w hour counter
  • Switch over device for 200 or 300 bar
  • Motor protection switch
  • Special voltages / frequencies on request
  • Conversion set: Petrol-/electro version


Technical Data


LW 160 E
Type: Air cooled piston compressor
Capacity [l/min] / [Nm³/h] / [cfm]: 160 / 9.6 / 5.6
Max. Pressure [bar]: 330
RPM [1/min]: 1450
No of cylinders / No of stages: 3 / 3
Prime mover type: E-Motor / 400V / 3 Phase / 50 Hz
Drive power [kW] / [HP]: 4.0 / 5.5
Cooling air requirement [Nm³/h]: 1200
Lubrication type: Splash oil
Oil capacity [l]: 0.8
Operating temperature [°C]: +5°C to +45°C
Filter capacity [m³ at +20°C]: 180 (approx. 19 h)
Dimensions L x W x H [cm]: 78 x 42 x 56
Weight [kg]: 90
Noise level (measured at 1 m) [dB]: 84
